The Panaray 802 installed sound-reinforcement loudspeaker features a full-range-driver array, eliminating the need for tweeters and crossovers, to provide unsurpassed reliability and vocal clarity. The Articulated Array design, with wide 120° x 100° coverage, can reduce the number of required loudspeakers, while the 52-Hz low- frequency range can reduce the need for subwoofers, providing a cost-effective solution for many indoor or outdoor installed sound-reinforcement applications.
Product Overview
Frequency Range (-10 dB) 52 Hz – 15 kHz
- Sensitivity (SPL / 1 W @ 1 m) 92 dB SPL
- Nominal Coverage Pattern (H x V) 120° H x 100° V
- Nominal Impedance 8 Ω
Long-Term Power Handling
- Bose extended-lifecycle test⁴: 240 W
- AES transducer test⁵: 300 W
Power Handling, Peak
- Bose extended-lifecycle test⁴: 960 W
- AES transducer test⁵: 1200 W
Calculated Maximum SPL @ 1 m
- Bose extended-lifecycle test⁴: 116 dB SPL
- AES transducer test⁵: 117 dB
Calculated Maximum SPL @ 1 m, peak
- Bose extended-lifecycle test⁴: 122 dB
- AES transducer test⁵: 123 dB
Key Features
- Full-Range-Driver Array eliminates tweeters and crossovers for unsurpassed reliability in harsh environments and vocal clarity.
- 8x Bose 4.5-inch full-range drivers for legendary reliability
- 120° x 100° Articulated Array® design covers a very wide area, which can reduce the number of loudspeakers required
- 52 Hz – 15 kHz Frequency Range eliminates need for subwoofers for moderate full-range music levels
- 123 dB Peak SPL for sound-reinforcement and foreground music
- Rugged, lightweight enclosure with threaded inserts for easy installations
- Weather-Rated Design for indoor or outdoor installations
- Requires Active Equalization
Physical
- Enclosure – Mineral-reinforced HDPE
- Environmental – Outdoor per IEC 529 IP55
- Connectors – Two (2) parallel-wired NL4 Neutrik® Speakon® connectors
- Suspension / Mounting – 8 x M8 threaded inserts (2 back, 2 bottom, 4 sides)
- Dimensions (Enclosure only) – 13.3″ H x 20.5″ W x 13.2″ D (338 mm x 520 mm x 335 mm)
- Net Weight – 30 lb (13.6 kg)
- Color – Black
- Package Contents – 1 loudspeaker
