Imagine the pickups out of an old ’52 gold top or a ’59 ES-330. By removing the cover you’ll find the same hand-fabricated bobbins, wire and “flatback” tape that was used in the originals. Two specially calibrated Dun-Aged Alnico II magnets are attached to a precision metal spacer which transfers the magnetic field to the strings via six fillister head pole pieces. The “dog ear” version comes with an aged thermoformed black cover. All versions have an authoritative, vintage tone.

Antiquity P-90 Dog Ear Version Neck

Specifications
Top Pickup Length: 3.158
Top Pickup Width: 1.205
Bottom Plate Length: 3.30
Bottom Plate Width: 1.295
Total Pickup Height: .640
Total Magnet Height: .125
Winding Direction: Top Going
Pickup Cover Length: 4.645
Pickup Cover Width: 1.60
Pickup Cover Height: .315
Magnet Polarity: North
Center to Center: 3.825
Calibrated: Yes
Height Adjustment: Mounted in Cavity

Antiquity P-90 Dog Ear Version Bridge

Specifications
Top Pickup Length: 3.158
Top Pickup Width: 1.205
Bottom Plate Length: 3.30
Bottom Plate Width: 1.295
Total Pickup Height: .640
Total Magnet Height: .125
Winding Direction: Top Coming
Pickup Cover Length: 4.645
Pickup Cover Width: 1.60
Pickup Cover Height: .450
Magnet Polarity: South
Center to Center: 3.825
Calibrated: Yes
Height Adjustment: Mounted in Cavity
Magnet Pattern: 2 Bar Magnets
DC Ohms: 8.52k
Inductance: 7.41 henries
Q: 2.84
Magnet Pattern: 2 Bar Magnets
DC Ohms: 7.9K
Inductance: 6.85 Henries
Q: 2.84
