AT2041SP Studio Pack
Studio miking essentials

The AT2041SP Studio Pack offers two versatile 20 Series condenser microphones for use in home, project and commercial studios. Equally at home with digital and analog recording devices, the two included studio condensers deliver remarkable specs and superior build. The critically acclaimed AT2020 side-address condenser is ideal for vocal and instrument applications, while the new AT2021 small-diaphragm condenser is a natural for acoustic instruments, overheads, hi-hat and piano.

Audio-Technica’s stringent quality/consistency standards set both microphones apart from other mics in their class. Each offers a wide dynamic range and handles high SPLs with ease. An innovative pivoting stand mount is included along with a microphone clip and protective pouches.

Now with SONAR LE
The AT2041SP now comes bundled with Cakewalk’s SONAR LE feature-rich recording software for musicians using PC-based recording. SONAR LE provides a cutting-edge music production studio, giving users what they need to get started creating music on Windows XP, X64, or Vista PCs.

AT2041SP Studio Pack includes:
AT2020 Side-address cardioid condenser microphone
AT2021 Small-diaphragm cardioid condenser microphone
SONAR LE recording software
Pivoting, threaded stand mount for the AT2020
Professional stand clamp for the AT2021
Two protective pouches

About the microphones
AT2020 Side-address cardioid condenser microphone

The price/performance standard in side-address studio condenser microphone technology

Ideal for project/home-studio applications

High SPL handling and wide dynamic range provide unmatched versatility

Custom-engineered low-mass diaphragm provides extended frequency response and superior transient response

Cardioid polar pattern reduces pickup of sounds from the sides and rear, improving isolation of desired sound source

Pivoting, threaded stand mount attaches securely for easy and precise placement of the microphone

AT2021 Small-diaphragm cardioid condenser microphone

Ideal for acoustic guitar, overheads, piano and group vocals

Condenser design for studio-quality vocal and instrument applications

Excels in high-SPL applications

Extended response for smooth, natural sonic characteristics

Low-mass element for superb transient response

Corrosion-resistant contacts from gold-plated XLRM-type connector

Rugged design and construction for reliable performance

Cardioid polar pattern reduces pickup of sounds from the sides and rear, improving isolation of desired sound source

SPECIFICATIONS:

ELEMENT: Fixed-charge back plate, permanently polarized condenser
POLAR PATTERN: Cardioid
FREQUENCY RESPONSE: AT2020: 20-20,000 Hz AT2021: 30-20,000 Hz
OPEN CIRCUIT SENSITIVITY: AT2020: 37 dB (14.1 mV) re 1V at 1 Pa
AT2021: 39 dB (11.2 mV) re 1V at 1 Pa
IMPEDANCE AT2020: 100 ohms
AT2021: 250 ohms
MAXIMUM INPUT SOUND LEVEL AT2020: 144 dB SPL, 1 kHz at 1% T.H.D.
AT2021: 145 dB SPL, 1 kHz at 1% T.H.D.
NOISE AT2020: 20 dB SPL
AT2021: 19 dB SPL

DYNAMIC RANGE (typical):
AT2020: 124 dB, 1 kHz at Max SPL
AT2021: 126 dB, 1 kHz at Max SPL

SIGNAL-TO-NOISE RATIO:
AT2020: 74 dB, 1 kHz at 1 Pa
AT2021: 75 dB, 1 kHz at 1 Pa

PHANTOM POWER REQUIREMENTS: 48V DC, 2 mA typical
WEIGHT: AT2020: 12.1 oz (345 g) AT2021: 2.9 oz (83 g)
DIMENSIONS: AT2020: 6.38″ (162.0 mm) long, 2.05″ (52.0 mm) maximum body diameter
AT2021: 4.00″ (101.5 mm) long, 0.83″ (21.0 mm) maximum body diameter
OUTPUT CONNECTOR: Integral 3-pin XLRM-type
ACCESSORIES FURNISHED:
AT2020: Stand mount for 5/8″-27 threaded stands; 5/8″-27 to 3/8″-16 threaded adapter; soft protective pouch
AT2021: Stand clamp; soft protective pouch
