CELESTION Classic Series G12H-75 Creamback 8 ohm Guitar Speaker

$169.00

Celestion Classic Series G12H-75 Creamback 8 ohm Guitar Speaker

Out of stock

Accepted Payments

Description

Back in the late 60s, the G12H was created by fixing an ‘H’ type (heavy) magnet to the body of a G12M guitar speaker. Result: a speaker with more power and a different tonal balance: firmer bass and a more pronounced top end. So we added an ‘H’ magnet to the G12M-65 Creamback, create a speaker that delivers the sonic signature of a G12H combined with Creamback levels of power handling. The result is the G12H-75 Creamback. It delivers 75-watts of power handling with ease and has unmistakeable G12H tone, with a tighter low end than the G12M-65 Creamback and a punchier, more dynamic high end. The H magnet brings additional focus, body and girth to the Creamback tone. It thickens single notes, resulting in a highly articulate, vocal character. These additional characteristics mean that the G12H-75 Creamback offers exceptional performance when used for lead guitar and sounds massive loaded into a 4×12 cab!

General Specifications

  • Nominal diameter: 12″, 305mm
  • Power rating: 75W
  • Nominal impedance: Available 8 ohms or 15 ohms
  • Sensitivity: 100dB
  • Chassis type: Pressed steel
  • Voice coil diameter: 1.75″, 44.5mm
  • Magnet type: Ceramic
  • Magnet weight: 50oz, 1.42kg
  • Frequency range: 70-5000Hz
  • Resonance frequency, Fs: 75Hz
  • DC resistance, Re: 6.37 ohms and 12.5 ohms
  • Voice coil former material: Round copper

Mounting Information

  • Cut-out diameter: 11.1″, 283mm
  • Diameter: 12.2″, 309mm
  • Magnet structure diameter: 6.6″, 168mm
  • Mounting slot dimensions: 0.31″, 7.9mm
  • Mounting slot PCD: 11.7″, 297mm
  • Number of mounting slots: 8
  • Overall depth: 5.4″, 138mm
  • Unit weight: 10.4lb, 4.7kg
